How to Use Window Functions in SQL

Introduction

The OVER clause in SQL is used to define a window, or a set of rows, for functions to operate over. This clause is essential in window functions, which perform calculations across a set of table rows that are somehow related to the current row. Unlike aggregate functions, which return a single result for a group of rows, window functions return a value for each row based on the defined window.

Common Uses of ‘OVER’:

1. Partitioning: The PARTITION BY clause within OVER divides the result set into partitions to which the window function is applied independently.

   Example:

   SUM(sales) OVER (PARTITION BY region)


   This calculates the sum of sales for each region.

2. Ordering: The ORDER BY clause within OVER specifies the order of rows within each partition.

   Example:

   ROW_NUMBER() OVER (ORDER BY date)


   This assigns a unique sequential integer to rows within a result set, ordered by date.

3. Range or Rows: The RANGE or ROWS clauses within OVER allow you to define a specific frame of rows relative to the current row.

   Example:

   SUM(sales) OVER (ORDER BY date ROWS BETWEEN 1 PRECEDING AND 1 FOLLOWING)


   This calculates a moving sum, including the current row, the previous row, and the next row.

Examples of Window Functions Using ‘OVER’:

• Ranking Functions: ROW_NUMBER(), RANK(), DENSE_RANK()

  Example:

  SELECT employee_id, salary,
         RANK() OVER (ORDER BY salary DESC) AS salary_rank
  FROM employees;


• Aggregate Functions: SUM(), AVG(), MIN(), MAX()

  Example:

  SELECT department, employee_id, salary,
         SUM(salary) OVER (PARTITION BY department) AS department_total
  FROM employees;


• Offset Functions: LAG(), LEAD()

  Example:

  SELECT employee_id, salary,
         LAG(salary, 1) OVER (ORDER BY hire_date) AS previous_salary
  FROM employees;


In summary, the OVER clause defines the context or “window” within which a window function operates, allowing you to perform complex calculations and analysis that consider each row’s relationship to others.

Examples of Using ‘OVER’ Clause

The OVER clause is quite powerful in SQL, and it’s used in a variety of scenarios to perform calculations across a set of rows related to the current row. Below are more detailed explanations and examples of different ways to use the OVER clause in SQL.

Sample Table:

Table: EmployeeSalaries

EmployeeID	Name	Department	Salary	HireDate
1	Alice	HR	50000	2020-01-15
2	Bob	IT	60000	2019-11-10
3	Charlie	HR	55000	2021-03-22
4	David	IT	70000	2018-06-01
5	Eva	IT	75000	2019-04-19
6	Frank	HR	52000	2021-08-03
7	Grace	IT	69000	2020-12-11
8	Henry	IT	60000	2022-02-15
9	Irene	HR	52000	2022-05-10

Example 1: SUM() Function with ‘OVER’ Clause

The SUM() function, when used with the OVER clause in SQL, allows you to perform cumulative or running totals, or sum values across a specified partition of data without collapsing the rows into a single output. This is very useful when you need to calculate totals while still retaining the detail of each row.

SELECT
    EmployeeID,
    Name,
    Department,
    Salary,
    SUM(Salary) OVER (PARTITION BY Department) AS DepartmentTotal
FROM EmployeeSalaries;

Result:

EmployeeID	Name	Department	Salary	DepartmentTotal
1	Alice	HR	50000	209000
3	Charlie	HR	55000	209000
6	Frank	HR	52000	209000
9	Irene	HR	52000	209000
2	Bob	IT	60000	334000
4	David	IT	70000	334000
5	Eva	IT	75000	334000
7	Grace	IT	69000	334000
8	Henry	IT	60000	334000

Explanation: The SUM(Salary) OVER (PARTITION BY Department) calculates the total salary within each department and displays that total for each row within the department.

Example 2: ROW_NUMBER() Function with ‘OVER’ Clause

The ROW_NUMBER() function in SQL is used to assign a unique sequential integer to rows within a result set. When combined with the OVER clause, it allows you to determine the order in which the rows are numbered. The numbering starts at 1 and increments by 1 for each row.

The ROW_NUMBER() function with the OVER clause is a versatile tool in SQL for ranking, partitioning, and filtering data, providing a flexible way to analyze and manipulate rows in a dataset.

SELECT
    EmployeeID,
    Name,
    Department,
    Salary,
    ROW_NUMBER() OVER (PARTITION BY Department ORDER BY Salary DESC) AS SalaryRank
FROM EmployeeSalaries;

Result:

EmployeeID	Name	Department	Salary	SalaryRank
3	Charlie	HR	55000	1
6	Frank	HR	52000	2
9	Irene	HR	52000	3
1	Alice	HR	50000	4
5	Eva	IT	75000	1
4	David	IT	70000	2
7	Grace	IT	69000	3
2	Bob	IT	60000	4
8	Henry	IT	60000	5

Explanation: The ROW_NUMBER() function assigns a unique rank within each department based on the salary, with the highest salary getting a rank of 1.

Example 3. RANK() Function with ‘OVER’ Clause

The RANK() function with the OVER clause in SQL assigns a rank to each row within a result set based on the order specified in the OVER clause. If there are ties (rows with the same values in the ranking criteria), RANK() assigns the same rank to those rows, but the next rank is skipped. This function is useful for ranking items within partitions of data, such as determining the top performers within each department.

SELECT
    EmployeeID,
    Name,
    Department,
    Salary,
    RANK() OVER (PARTITION BY Department ORDER BY Salary DESC) AS SalaryRank
FROM EmployeeSalaries;

Result:

EmployeeID	Name	Department	Salary	SalaryRank
3	Charlie	HR	55000	1
6	Frank	HR	52000	2
9	Irene	HR	52000	2
1	Alice	HR	50000	4
5	Eva	IT	75000	1
4	David	IT	70000	2
7	Grace	IT	69000	3
2	Bob	IT	60000	4
8	Henry	IT	60000	4

Explanation: The RANK() function ranks employees within their departments by salary. Tied salaries would receive the same rank, but the next rank would be skipped.

Example 4. DENSE_RANK() Function with ‘OVER’ Clause

The DENSE_RANK() function with the OVER clause in SQL assigns a rank to each row within a result set, similar to RANK(), but without skipping any ranks when there are ties. If multiple rows have the same rank, the next rank in the sequence is not skipped. This function is useful for ranking items in a dense manner within partitions of data, such as listing top salespeople without gaps in ranking numbers.

SELECT
    EmployeeID,
    Name,
    Department,
    Salary,
    DENSE_RANK() OVER (PARTITION BY Department ORDER BY Salary DESC) AS DenseSalaryRank
FROM EmployeeSalaries;

Result:

EmployeeID	Name	Department	Salary	DenseSalaryRank
3	Charlie	HR	55000	1
6	Frank	HR	52000	2
9	Irene	HR	52000	2
1	Alice	HR	50000	3
5	Eva	IT	75000	1
4	David	IT	70000	2
7	Grace	IT	69000	3
2	Bob	IT	60000	4
8	Henry	IT	60000	4

Explanation: The DENSE_RANK() function also ranks employees by salary within their department but doesn’t skip any ranks if there are ties.

Example 5. NTILE() Function with ‘OVER’ Clause

The NTILE() function with the OVER clause in SQL divides the result set into a specified number of approximately equal groups, or “tiles,” and assigns a number to each row indicating the tile it belongs to. This function is useful for creating quartiles, deciles, or any other form of data segmentation.

SELECT
    EmployeeID,
    Name,
    Department,
    Salary,
    NTILE(3) OVER (ORDER BY Salary DESC) AS SalaryQuartile
FROM EmployeeSalaries;

Result:

EmployeeID	Name	Department	Salary	SalaryQuartile
5	Eva	IT	75000	1
4	David	IT	70000	1
7	Grace	IT	69000	1
3	Charlie	HR	55000	2
6	Frank	HR	52000	2
9	Irene	HR	52000	2
2	Bob	IT	60000	3
8	Henry	IT	60000	3
1	Alice	HR	50000	3

Explanation: The NTILE(3) function divides the rows into three groups based on the salary. The highest salaries go into the first group, and so on.

Example 6. CUME_DIST() Function with ‘OVER’ Clause

The CUME_DIST() function with the OVER clause in SQL calculates the cumulative distribution of a value within a result set. It returns a value between 0 and 1, representing the proportion of rows with values less than or equal to the current row’s value. This function is useful for understanding the relative standing of a row within a set of values.

SELECT
    EmployeeID,
    Name,
    Department,
    Salary,
    CUME_DIST() OVER (ORDER BY Salary DESC) AS CumulativeDistribution
FROM EmployeeSalaries;

Result:

EmployeeID	Name	Department	Salary	CumulativeDistribution
5	Eva	IT	75000	0.1111
4	David	IT	70000	0.2222
7	Grace	IT	69000	0.3333
3	Charlie	HR	55000	0.5556
6	Frank	HR	52000	0.7778
9	Irene	HR	52000	0.7778
2	Bob	IT	60000	0.7778
8	Henry	IT	60000	0.7778
1	Alice	HR	50000	1.0000

Explanation:

• CUME_DIST() calculates the cumulative distribution by dividing the rank of the current row by the total number of rows.
• Eva has the highest salary (75,000), so her CumulativeDistribution is 1/9 = 0.1111, indicating that 11.11% of the employees have a salary less than or equal to hers.
• David is next with a salary of 70,000, so his CumulativeDistribution is 2/9 = 0.2222, indicating that 22.22% of the employees have a salary less than or equal to his.
• Grace follows with a salary of 69,000, giving her a CumulativeDistribution of 3/9 = 0.3333.
• Charlie has a salary of 55,000, and his CumulativeDistribution is 5/9 = 0.5556.
• Frank and Irene have the same salary of 52,000, and since they are tied, they share the same CumulativeDistribution of 7/9 = 0.7778.
• Bob and Henry also share a salary of 60,000, so their CumulativeDistribution is also 7/9 = 0.7778.
• Alice has the lowest salary (50,000), and her CumulativeDistribution is 9/9 = 1.0000, indicating that all employees have a salary less than or equal to hers.

Example 7. LEAD() and LAG() with ‘OVER’ Clause

The LEAD() and LAG() functions with the OVER clause in SQL are used to access data from subsequent or previous rows in a result set, respectively.

• LAG() retrieves data from a specified number of rows before the current row.
• LEAD() retrieves data from a specified number of rows after the current row.

These functions are useful for comparing values between rows, such as tracking changes over time or calculating differences between consecutive records.

SELECT
    EmployeeID,
    Name,
    Department,
    Salary,
    LAG(Salary, 1) OVER (ORDER BY Salary DESC) AS PreviousSalary,
    LEAD(Salary, 1) OVER (ORDER BY Salary DESC) AS NextSalary
FROM EmployeeSalaries;

Result:

EmployeeID	Name	Department	Salary	PreviousSalary	NextSalary
5	Eva	IT	75000	NULL	70000
4	David	IT	70000	75000	69000
7	Grace	IT	69000	70000	60000
2	Bob	IT	60000	69000	60000
8	Henry	IT	60000	60000	55000
3	Charlie	HR	55000	60000	52000
6	Frank	HR	52000	55000	52000
9	Irene	HR	52000	52000	50000
1	Alice	HR	50000	52000	NULL

Explanation: LAG() retrieves the salary of the previous employee (in descending salary order), while LEAD() retrieves the salary of the next employee. This can be useful for calculating differences or trends between rows.

Example 8. PERCENT_RANK() with ‘OVER’ Clause

The PERCENT_RANK() function with the OVER clause in SQL calculates the relative rank of a row as a percentage of the total number of rows in the result set. It returns a value between 0 and 1, representing where a row stands in relation to others, with the first row being 0 and the last row being 1. This function is useful for understanding the relative position of a value within a dataset.

SELECT
    EmployeeID,
    Name,
    Department,
    Salary,
    PERCENT_RANK() OVER (ORDER BY Salary DESC) AS PercentRank
FROM EmployeeSalaries;

Result:

EmployeeID	Name	Department	Salary	PercentRank
5	Eva	IT	75000	0.0000
4	David	IT	70000	0.1250
7	Grace	IT	69000	0.2500
2	Bob	IT	60000	0.5000
8	Henry	IT	60000	0.5000
3	Charlie	HR	55000	0.7500
6	Frank	HR	52000	0.8750
9	Irene	HR	52000	0.8750
1	Alice	HR	50000	1.0000

Explanation: The PERCENT_RANK() function gives each row’s rank as a percentage of the total number of rows, ranging from 0 to 1.

Conclusion

The OVER clause in SQL is incredibly versatile and can be combined with various functions to perform advanced calculations on your data. These examples cover many common scenarios where you might use the OVER clause, such as ranking, cumulative distribution, and moving averages. Understanding how to use OVER can significantly enhance your ability to analyze and manipulate data in SQL.
